Description
- Brand Name: LanYuXuan
- Certification: CE
- Origin: CN(Origin)
- Warranty: 1 year
- Customized support: OEM
- Place of Origin: China
- Model Number: WN700S WN700D
- Commodity Number: 9
- Geometric Conditions: d/8
- Light Source: Combined LED
- Wavelength coverage: 400nm~700nm
- Wavelength interval: 10nm
- Measuring interval: 2.5 Second
#detail_decorate_root .magic-0{border-bottom-style:solid;border-bottom-color:#53647a;font-family:Roboto;font-size:24px;color:#53647a;font-style:normal;border-bottom-width:2px;padding-top:8px;padding-bottom:4px}#detail_decorate_root .magic-1{margin-bottom:10px;overflow:hidden}#detail_decorate_root .magic-2{width:750px}#detail_decorate_root .magic-3{overflow:hidden;width:247.33333333333334px;height:247.33333333333337px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-4{margin-top:0;margin-left:0;width:247px;height:247px}#detail_decorate_root .magic-5{overflow:hidden;width:247.33333333333334px;height:247.33333333333337px;margin-top:0;margin-bottom:0;margin-left:4px;margin-right:0}#detail_decorate_root .magic-6{vertical-align:top}#detail_decorate_root .magic-7{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-8{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root .magic-9{padding:0;margin:0;white-space:pre-wrap;font-size:14px}#detail_decorate_root .magic-10{padding:0;margin:0;color:#333;font-size:14px;padding-left:4px;font-weight:bold;white-space:pre-wrap}#detail_decorate_root .magic-11{width:750px;border-collapse:collapse}#detail_decorate_root .magic-12{min-height:18px;padding:5px 10px;width:157px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-13{min-height:18px;padding:5px 10px;width:243px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-14{min-height:18px;padding:5px 10px;width:285px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-15{min-height:18px;padding:5px 10px;width:549px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-16{display:none}#detail_decorate_root .magic-17{min-height:18px;padding:5px 10px;width:286px;min-height:18px;box-sizing:content-box}
Recommend Products
Products Display
Product Description
WN700S with competitive price, high quality,high accuracy,easy to operate, easy to understand, affordable and so on.
Main Feature
1.Adopts advanced electronic circuit system and perfect optical system 2.High precision, good stability and strong anti-interference 3.Multi aperture design,large application 4. Rechargeable, high capacity lithium battery.
Technical Data
|
Model
|
WN700D(Single Caliber)
|
WN700S(Switchable Caliber)
|
|
|
Geometric Conditions
|
d/8
|
||
|
Color Space
|
CIEL*a*b*、CIEL*C*h、Yxy
|
CIEL*a*b*、CIEL*C*h、CIEL*u*v*、Hunter LAB、CIEXYZ、Yxy、Reflectivity、CMYK、YI Yellowness、Ganz、ISO Brightness(R457 Whiteness)、Taube
Whiteness、z Whiteness、sRGB |
|
|
Standard Light Source
|
A、C、D50、D65、F2（CWF）、F12(U30)
|
A、C、D50、D55、D65、D75、F1、F2（CWF）、F3、F4、F5、F6、F7、F8、F9、F10、F11(TL84)、F12(U30)
|
|
|
Light Source
|
Combined LED
|
||
|
Color Diff. Formula
|
△E*ab、△E*Ch
|
△E*ab、△E*Ch、△E*uv、 △E*Hunter、△E*cmc(2:1)、△E*cmc(1:1)、△E*94、△E*00、△E*sRGB、△E*BFD、△E*FMCII
|
|
|
Measuring Caliber
|
Facula 4mm(Caliber Φ6mm)、 Facula 8mm(Caliber Φ11mm)、Facula 16mm(Caliber Φ16mm)
|
Switchable: Facula 4mm(Caliber Φ6mm)& Facula 8mm(Caliber Φ11mm) Single: Facula 16mm(Caliber Φ16mm)
|
|
|
SCI/SCE
|
SCI
|
SCI/SCE
|
|
|
Sensor Array
|
Line array CMOS@256 pixels
|
||
|
Spectral Way
|
Concave diffraction grating
|
||
|
Observer
|
CIE10°(1964)、CIE2°(1931)
|
||
|
Wavelength coverage
|
400nm~700nm
|
||
|
Wavelength interval
|
10nm
|
||
|
Measuring interval
|
2.5 Second
|
||
|
Reflectance range
|
0%-200%
|
||
|
Repeated accuracy
|
△E＜0.07 （take the deviation average after 30 times measuring the whiteboard）
|
△E＜0.05 （take the deviation average after 30 times measuring the whiteboard）
|
|
|
Table Difference
|
△E＜0.4(Measure the RAL 12-color blocks)
|
△E＜0.3(Measure the RAL 12-color blocks)
|
|
|
Light source life
|
More than 50,000 hours
|
||
|
Battery power
|
Measuring more than 10000 times
|
||
|
Display screen
|
TFT true color 2.8inch@(16:9)
|
||
|
Data storage capacity
|
Storage Standard 100 groups
|
||
|
Sample 16,000 groups
|
|||
|
Operating temperature
|
0℃-40℃（32℉-104℉）
|
||
|
Storage temperature
|
-20℃-50℃（-4℉-122℉）
|
||
|
Working humidity
|
Relative humidity less than 85%,without condensation
|
||
|
G.W
|
1.5kgs
|
5.5kgs
|
|
|
Size of exterior package
|
28*19*11cm
|
39*34*20cm
|
|
|
Standard accessories
|
Power adapter, standard white board, standard black cavity, lithium battery, specification, PC software
|
||
|
Optional accessories
|
Software(Advanced Version), Micro printer, Locating block
|
||
